REDTIGER F7N Dash Cam Hardwire Kit USB C Port, Dashboard Camera Car Charger Cable Kit 12V- 24V to 5V w/Fuse Kit, Low Voltage Protection for Dash Cam Double-4 Fuses

About This

• Wide CompatibleInput:12V-24V; Output:5V/2A. With Type-C ports, this hardwire kit compatible with all of dash cams.
• EASY TO INSTALL With the installation tool, there's no need to use a cable from car cigarette lighter socket, instead it's a permanent hidden cable, and very easy to install.
• 24 HOURS MONITOR24 Hours Surveillance: The vehicle hard-wire kit connect to car battery or fuse box power, can realize continuous power supply for 24 hours. It can keep powered on even car turned off.
• LOW VOLTAGE PROTECTINGMultiple Security Protection - With low voltage protection, REDTIGER hardwire kit will automatically cut off the power after 60s when the voltage is lower than 11.8V+-0.2). Not applicable to trucks with voltage above 24V. More security protection like over-current, short-circuit, reverse connection, and overheat.

Overview

• Brand : REDTIGER
• Material : Copper (core), Polyvinyl Chloride (PVC) (insulation)
• Item dimensions L x W x H : 3 x 3 x 2 inches
• Connector Type : USB Type C
• The REDTIGER Hardwire Kit compatible with to all REDTIGER series dash cam .
• ( F7N/F7NP/F7NT/F7NS/F8/F9/F17/F4/F77 Mini Dash Cam and T27/T700 Mirror Dash Cams etc.)
• 1. Please make sure the ACC and BAT is connected correctly.
• 2. Please feel free to reach us if any professional help in need.
• 3. Please use the dedicated hardwire kit for the REDTIGER dash cam, Because the other brands of hardwire kits are not available for Redtiger dash cams.
• 4. The length of this hardwire kit is 11.5ft, various types of vehicles, especially regular passenger cars, sedans, SUVs, and trucks.
• 5. Therefore, when selecting a voltage hardwire kit, it is recommended to refer to the specifications and requirements of your vehicle and device to ensure compatibility and safety.
• 6. Note that installation steps may vary by model and situation. It is strongly recommended to refer to the vehicle manual or seek professional help before installation.
• Instructions for installation
• 1. Make sure everything is ready and safe before installation.
• 2. Locate the car's fuse box. It is usually located under the dashboard on the driver's side or in the engine compartment.
• 3. Identify the ACC (Accessory) fuse slot in the fuse box. This slot provides power when the ignition is on. Locate the constant power fuse slot in the fuse box. This slot provides power even when the ignition is off.
• 4. Connect the red wire from the hardwire kit to the ACC fuse slot. Connect the yellow wire from the hardwire kit to the constant power fuse slot. You can use a fuse tap or a fuse adapter to make the connection.
• 5. Find a suitable grounding point near the fuse box. It should be a metal surface that is securely connected to the vehicle's chassis.
• 6. Connect the black wire from the hardwire kit to the grounding point using a ring terminal or a suitable grounding connector.
• 7. Once all the connections are secure, tuck away any excess wires and ensure they are safely routed to avoid interference with the vehicle's controls.
• 8. Test the hardwire kit by turning on the ignition. The dash cam should receive power and start functioning.
• Ensure the safety of your vehicle's battery with the Redtiger Hardwire Kit. It features a low voltage protection mode that cuts off power when the voltage drops below 11.8V(+-0.2).
